Double-acting pneumatic air cylinder - Bimba (Original line air cylinder series) - 1-1/2" bore (B1-1/2") - 11" stroke (S11") - Front nose mounting - 7/16-20 UNF-2A (male) threaded rod + 3/4-16 threaded mounting nut - 2 x 1/8" NPT threaded pneumatic ports - Standard blackened carbon steel rod

Specifications

Primary brand

Bimba

Main function

Pneumatic cylinder

Product series / family name

Original line air cylinder series

Sub-range name

17 series

Bore size

1-1/2" bore (B1-1/2")

Stroke length

11" stroke (S11")

Functions

Double-acting pneumatic air cylinder

Design

Non-repairable

Connection type

2 x 1/8" NPT threaded pneumatic ports
7/16-20 UNF-2A (male) threaded rod
3/4-16 threaded mounting nut

Mounting mode

Front nose mounting

Material

Standard blackened carbon steel rod

Ambient air temperature for operation

-20...+200°F / -28...+93 °C

Manufacturer product status

Commercialized

Benefits

Wide variety of stroke lengths and mounting styles
Blue and Improved design doubles previous cylinder life
Permanent grease lubricant requires no additional lubrication during service
